Asus Rog Thor 1000W Platinum III Gaming Power Supply

Asus ROG Thor 1000W Platinum III targets high-end gaming and workstation builds.
It delivers stable power for modern GPUs and heavy workloads.
The design focuses on efficiency, cooling, and real-time monitoring.

---

Key Features

• GaN MOSFET for higher power efficiency and lower heat output.
• GPU-First intelligent voltage stabilizer for stable GPU power delivery.
• Magnetic OLED display showing real-time power usage.
• ATX 3.1 support with native PCIe 5.0 16-pin cable up to 600W.
• 80 PLUS Platinum efficiency for lower heat and noise.

---

Technical Specifications

Model

• ROG Thor 1000W Platinum III 90YE00V3-B0NA00

Power Output

• Total output 1000W

Form Factor and Standard

• ATX12V
• ATX 3.1 compliant

Efficiency

• 80 PLUS Platinum
• Up to 92 percent efficiency at 50 percent load

Input

• AC input range 100–240V
• Active PFC

Output Rails

• +3.3V
• +5V
• +12V
• -12V
• +5Vsb

Maximum Load

• +12V rail up to 83.33A

Cooling

• Large ROG heatsinks
• Dual ball bearing fan
• 0dB technology with fan stop under low load

Noise Control

• 0dB fan mode supported
• Manual 0dB fan button

Protection

• OPP
• OVP
• UVP
• SCP
• OCP
• OTP

MTBF

• Over 120,000 hours at 25°C

Dimensions

• 190 × 150 × 86 mm

Weight

• 2.37 kg

---

User Benefits

• You get stable power during gaming and overclocking.
• You reduce system noise under light loads.
• You monitor power usage directly from the PSU.
• You prepare your build for next-generation GPUs.

---

Compatibility

• PCIe 5.0 graphics cards
• ATX motherboards
• Aura Sync compatible systems

---

Included Items

• Power cord
• Motherboard power cable
• CPU power cables
• PCIe Gen 5.1 16-pin cable
• PCIe 6+2-pin cables
• SATA cables
• Peripheral cables
• Addressable RGB cable
• ROG stickers and cable ties
• Mounting screws
• User manual

---

Lighting

• Aura Sync ARGB support
• Smart lighting mode linked to GPU temperature
