GIGABYTE MB X670 AORUS ELITE AX

The GIGABYTE X670 AORUS ELITE AX motherboard is built for next-gen AMD performance, designed to support Ryzen 7000 Series processors and DDR5 memory. It delivers high-end connectivity, advanced thermal design, and overclocking capabilities. With PCIe 5.0 support, USB-C, Wi-Fi 6E, and Q-Flash Plus, it’s ideal for gamers and professionals looking for reliability, speed, and expandability. A solid power delivery system, Smart Fan 6, and customizable RGB lighting complete this AMD AM5 platform solution.

---

Technical Specifications

• Socket: AMD AM5

• Chipset: AMD X670

• Form Factor: ATX

• Memory Support: 4x DDR5 DIMM slots (up to 128GB)

• Memory Speed: Up to 6600MHz (OC)

• Storage Interface: 4x M.2 slots (PCIe 5.0/4.0), 6x SATA 6Gb/s

• Expansion Slots: 1x PCIe 5.0 x16, 1x PCIe 3.0 x16

• USB Ports: USB 3.2 Gen 2x2 Type-C, USB 3.2 Gen 2, USB 2.0

• Networking: Intel Wi-Fi 6E, 2.5GbE LAN, Bluetooth 5.3

• Audio: Realtek ALC1220-VB high-definition audio codec

• RGB: RGB Fusion with 2x addressable and 2x RGB LED headers

• BIOS: Q-Flash Plus, Dual BIOS

---

Key Features

• DDR5 Support: Up to 128GB with 6600MHz OC speeds

• PCIe 5.0 Ready: For ultra-fast GPUs and Gen5 SSDs

• Wi-Fi 6E + 2.5GbE LAN: Next-gen networking for gaming and streaming

• Q-Flash Plus: Update BIOS without CPU, RAM, or GPU installed

• Smart Fan 6: Advanced thermal control with multiple sensors

---

User Benefits

• Faster Multitasking: Full support for DDR5 memory and Ryzen 7000 Series CPUs

• Enhanced Gaming: PCIe 5.0 support for high-bandwidth GPUs

• Stable Temperatures: Optimized heatsinks and Smart Fan 6 for cool operation

• Easy Upgrades: Multiple M.2 slots and PCIe lanes allow expansion

• Modern Connectivity: Includes Wi-Fi 6E, USB-C, and fast LAN

---

Compatibility

• Supports AMD Ryzen 7000 Series processors

• Compatible with DDR5 memory up to 6600MHz (OC)

• Fits standard ATX cases

• Works with Gen5 SSDs, PCIe 4.0 GPUs, and USB-C accessories

---

Included Items

• GIGABYTE X670 AORUS ELITE AX Motherboard

• Wi-Fi Antenna

• SATA Cables

• M.2 Screws

• User Manual

• Quick Installation Guide
