Gigabyte MB Z690 GAMING X DDR4 (rev. 1.0)

The GIGABYTE Z690 GAMING X DDR4 (Rev. 1.0) motherboard is designed for gamers and PC builders using Intel's 12th and 13th Gen Core processors with DDR4 memory. Featuring PCIe 5.0 support, multiple M.2 slots, and 16+1+2 phase VRM power design, it provides solid performance, stability, and expandability for mainstream gaming and productivity systems. With integrated RGB support and Smart Fan 6, it offers both visual customization and thermal efficiency.

---

Technical Specifications

• Socket: Intel LGA 1700

• Chipset: Intel Z690

• Form Factor: ATX

• Memory Support:

  • 4× DDR4 DIMM slots (up to 128GB)

  • Supports up to 5333MHz (OC)

• Storage Interface:

  • 3× M.2 PCIe 4.0 x4 slots

  • 6× SATA 6Gb/s ports

• Expansion Slots:

  • 1× PCIe 5.0 x16

  • 2× PCIe 3.0 x16

• Networking:

  • 2.5GbE LAN (Realtek)

• Audio: Realtek ALC897

• USB Ports:

  • USB 3.2 Gen 2 Type-C

  • USB 3.2 Gen 1

  • USB 2.0

• RGB: RGB Fusion 2.0 with ARGB/RGB headers

• Cooling: Smart Fan 6 with multiple temperature sensors

• Power Design: 16+1+2 Digital VRM

---

Key Features

• Intel 12th/13th Gen CPU Support with LGA 1700 socket

• DDR4 Memory Compatibility up to 128GB and 5333MHz (OC)

• PCIe 5.0 Ready for future GPU upgrades

• 3× M.2 Slots with thermal guards for fast SSDs

• Advanced VRM Cooling with enlarged heatsinks

---

User Benefits

• Smooth Gaming & Workflow using powerful CPU and fast storage

• Future-Proof PCIe 5.0 Support for next-gen graphics cards

• Thermal Stability with Smart Fan 6 and full VRM coverage

• Customizable Lighting through RGB Fusion 2.0

• Reliable Power Delivery with 16+1+2 digital phases

---

Compatibility

• Supports Intel 12th and 13th Gen Core processors

• Compatible with DDR4 memory modules

• Fits standard ATX cases

• Supports PCIe 5.0 GPUs and Gen4 NVMe SSDs

---

Included Items

• GIGABYTE Z690 GAMING X DDR4 Motherboard

• SATA Cables

• M.2 Screws

• User Manual

• Quick Installation Guide
