Gigabyte Z690 UD AX (rev. 1.0) LGA 1700 DDR5 ATX - Motherboard

The GIGABYTE Z690 UD AX DDR5 (Rev. 1.0) is a durable and future-ready ATX motherboard built for Intel 12th and 13th Gen Core processors. It supports DDR5 memory for faster performance, PCIe 5.0 for next-gen graphics, and includes built-in Wi-Fi 6 and 2.5GbE LAN. Designed for stable power delivery and efficient cooling, it's ideal for users who want high performance and upgrade options without added cost.

---

Technical Specifications

• Socket: Intel LGA 1700

• Chipset: Intel Z690

• Form Factor: ATX

• Memory Support:

  • 4× DDR5 DIMM slots (up to 128GB)

  • Supports speeds up to 6000MHz (OC)

• Storage:

  • 3× M.2 PCIe 4.0 x4 slots

  • 6× SATA 6Gb/s ports

• Expansion Slots:

  • 1× PCIe 5.0 x16

  • 1× PCIe 3.0 x16

  • 2× PCIe 3.0 x1

• Networking:

  • Intel Wi-Fi 6

  • Bluetooth 5.2

  • 2.5GbE LAN (Realtek)

• Audio: Realtek ALC897 HD

• USB Ports:

  • USB 3.2 Gen 2x2 Type-C

  • USB 3.2 Gen 1 / Gen 2

  • USB 2.0

• Cooling: Smart Fan 6 with multiple temp sensors

• Power Design: 16+1+2 phase digital VRM with DrMOS

• BIOS: Q-Flash Plus

---

Key Features

• Supports Intel 12th & 13th Gen CPUs with LGA 1700

• DDR5 Memory Support for improved speed and efficiency

• PCIe 5.0 x16 Slot for next-gen GPU performance

• Wi-Fi 6 + 2.5GbE LAN for high-speed networking

• Triple M.2 Slots for high-speed NVMe SSDs

• Smart Fan 6 for adaptive thermal control

---

User Benefits

• Fast Multitasking & Gaming with DDR5 and PCIe 5.0 support

• Reliable Networking with built-in Wi-Fi 6 and LAN

• Smooth Storage Performance from triple M.2 slots

• Efficient Power Delivery for CPU stability under load

• Flexible Upgrade Path with future-ready components

---

Compatibility

• Compatible with Intel 12th and 13th Gen Core processors

• Supports DDR5 memory only

• Fits standard ATX cases

• Works with PCIe 5.0 GPUs and Gen4 M.2 SSDs

---

Included Items

• GIGABYTE Z690 UD AX DDR5 Motherboard

• Wi-Fi Antenna

• SATA Cables

• M.2 Screws

• User Manual

• Quick Installation Guide
