Geometric Future Model 8 Cowboy Mid Tower Glass Case - Black

The Geometric Future Model 8 Cowboy is a premium mid-tower case built for enthusiasts who demand high-end performance, advanced airflow, and a clean, professional look.
Crafted from 1.0mm steel with a 4.0mm tempered glass side panel, this case offers durability, visibility, and flexibility for both air and liquid cooling builds.
It supports E-ATX motherboards, full-length GPUs, and multiple radiator configurations, making it ideal for gaming or workstation setups that combine power and style.

---

Key Features

• Premium Construction – Durable 1.0mm steel frame with 4.0mm tempered glass panel
• Spacious Interior – Supports large components including GPUs up to 412mm and PSUs up to 220mm
• High Cooling Flexibility – Supports 360mm, 420mm, and 280mm radiators for extreme cooling performance
• Modern Connectivity – Includes USB Type-C (USB 3.1 Gen 2), 2× USB 3.0, 2× USB 2.0, and HD Audio (CTIA) ports
• Flexible GPU Mounting – Horizontal and vertical mounting options with full airflow clearance
• Advanced Airflow Design – Supports up to 9 fans for superior heat dissipation
• Elegant Black Finish – Stylish and professional look with clear tempered glass window

---

Technical Details

• Case Type: Mid Tower
• Material: Steel (1.0mm), Tempered Glass (4.0mm)
• Color: Black
• Dimensions (H × W × D): 500 × 230 × 500mm (19.7" × 9.1" × 19.7")
• Drive Bays:
  • Max: 3×3.5"
  • 3×2.5" / 6×2.5" tray
• Motherboard Compatibility:
  • E-ATX (12"×13")
  • ATX, Micro-ATX, Mini-ITX
• Power Supply Support:
  • ATX 12V (Length < 220mm)
• Expansion Slots:
  • PCI-E ×7: Length < 400mm (no bottom cooling) / Width < 175mm
  • Lateral PCI-E ×3: Length < 412mm / Width < 150mm / Height < 65mm
  • CPU Cooler Height < 105mm
• Cooling Support:
• Top: 120mm fan ×1 / 120mm radiator (optional)
• Rear: 120/140mm fan ×3 / 420mm radiator (L<470mm / T<55mm)
• Front: 360/280mm radiator (L<400mm / T<65mm)
• Bottom: 120/140mm fan ×3 / 360/280mm radiator (L<485mm)
• CPU Heatsink Height: <170mm
• I/O Ports:
  • 2× USB 3.0
  • 2× USB 2.0
  • 1× Type-C (USB 3.1 Gen 2)
  • 1× HD Audio (CTIA-SPK/MIC)

---

User Benefits

• Perfect for Enthusiasts: Designed for builders who want performance, cooling, and aesthetics in one chassis
• Next-Gen Connectivity: Front I/O ports include Type-C for high-speed data and power delivery
• Clean Cable Management: Spacious layout ensures easy and organized assembly
• Superior Airflow: Optimized ventilation and fan placement for consistent thermal balance
• Elegant Presentation: Showcase your build through the tempered glass side panel

---

Included Items

• Geometric Future Model 8 Cowboy Case – Black
• Mounting Screws and Accessories
• Pre-installed Dust Filters
• Quick Installation Guide
