Zotac Gaming GeForce RTX 5060 8GB GDDR7 128 Bit Mini Graphics Card - Black

The Zotac Gaming GeForce RTX 5060 Low Profile is a compact graphics card designed for small form factor systems without compromising modern performance. Built on NVIDIA RTX architecture, it supports advanced graphics features, AI acceleration, and high-resolution displays while fitting into low-profile PC builds.

Key Features

• Low profile design suitable for compact and small form factor systems.
• NVIDIA GeForce RTX 5060 GPU with AI and ray tracing support.
• 8GB GDDR7 memory on a 128-bit interface.
• PCI Express 5.0 x8 support for modern platforms.
• Multi-display support with DisplayPort 2.1b and HDMI 2.1b outputs.
• Air-cooled design with efficient thermal management.

Technical Specs

GPU Specifications

• GPU: NVIDIA GeForce RTX 5060
• CUDA Cores: 3840
• AI Performance: 614 AI TOPS
• Engine Clock: 2497 MHz

Memory Specifications

• Video Memory: 8GB
• Memory Type: GDDR7
• Memory Bus: 128-bit
• Memory Clock: 28 Gbps

Interface and Power

• Bus Interface: PCI Express 5.0 x8
• Power Consumption: 145W
• Recommended Power Supply: 550W
• Power Input: 1 x 8-pin

Display Support

• Display Outputs:
• 2 x DisplayPort 2.1b with UHBR20
• Supports up to 4K at 480Hz or 8K at 165Hz with DSC
• 1 x HDMI 2.1b
• Supports 4K at 480Hz HDR or 8K at 120Hz HDR with DSC and VRR
• HDCP: 2.3
• Multi-Display Support: Up to 3 displays

Software and API Support

• DirectX: Microsoft DirectX 12 Ultimate
• OpenGL: 4.6
• Supported Operating Systems: Windows 11, Windows 10 64-bit version 1809 or later

Physical and Cooling

• Cooling: Air cooled
• Slot Size: 2 slots
• Card Dimensions: 182.5 x 69 x 38.2 mm

Additional Information

• SLI Support: No

Included Accessories

• User manual
• Low-profile bracket
